The Essential Roaster for Daily Freshness – KUBAN Base 1.5 KG

The Kuban Base 1.5 kg Shop Coffee Roaster is a precision-crafted machine designed for specialty cafés, training labs, and boutique roasters. It offers a 1.5 kg batch capacity, making it ideal for developing roast profiles, producing fresh daily batches, or training baristas. The roaster provides repeatable consistency, flexible control, and robust engineering in a compact form.

Kuban’s 1.5 Kg Shop-Type Coffee Roaster

Technical Specifications

  • Model: KBN1000-M-1.5
  • Batch Capacity: 1.5 kg
  • Dimensions (W x H x D): 87 cm x 127 cm x 115 cm
  • Weight: 155 kg
  • Voltage Options: 110V, 220V, 230V, 380V
  • Frequency: 50–60 Hz
  • Heat Source Options: LPG, Natural Gas, Electric
  • Heating System: Thermal Transfer
  • Number of Motors: 4
  • Power Consumption: 1.84 kW/h
  • Burner Power: 10 kW
  • Gas Consumption:
    • LPG: 0.72 m³/h
    • Natural Gas: 1.04 m³/h
  • Gas Connector: 1/2 inch
  • Automation: Optional PLC System

Key Features

Kuban’s 1.5 Kg Shop-Type Coffee Roaster
  • Adjustable Drum Speed: The drum speed can be set up to 70 RPM, allowing for precise control over the roasting process.
  • Drum Construction: Available in single or double wall options to ensure consistency in the roasting profile.
  • Flame Level Adjustment: Users can adjust the flame level during the roasting process to achieve the desired roast profile.
  • Heating Source Flexibility: Compatible with LPG, LNG, Natural Gas, Diesel, and Electric heating sources.
  • Programmable Logic Controller (PLC): Optional touchscreen controller with software allows users to create and store unique roasting profiles.
  • Control Types: Available in manual, semi-automatic, and fully automatic variants.
  • Software Compatibility: Compatible with Artisan and Cropster roasting software via USB connection.
  • Customization: Roasters can be customized in terms of color, finishing, brand name, electric specifications (voltage and frequency), heating source, and language preferences.

Design and Build

The Kuban Base 1.5 kg roaster is constructed with high-quality materials, ensuring durability and longevity. Its compact size makes it suitable for environments with limited space without compromising on performance. The roaster’s design emphasizes user-friendly operation, making it accessible for both beginners and experienced roasters.

Additional Features

  • Cooling System: Equipped with a powerful fan and rotating system in the cooling chamber for efficient cooling of roasted beans.
  • Heat Insulation: Advanced heat insulation aids in energy conservation and maintains consistent roasting temperatures.
  • Quiet Operation: Designed for quiet running, making it suitable for café environments.
  • Easy Maintenance: The roaster’s design allows for straightforward maintenance and cleaning.
